Product Specifications
- 35 HP Kawasaki FX1000v (999cc) engine and 16cc Parker HTG transmission
Engine
-
Engine Brand: Kawasaki®
-
Engine Model: FX Series
-
Engine Model Number: 1000V
-
Engine Displacement: 999cc
-
Engine Output: 35HP
-
Fuel Tank Capacity: Dual 7.45 gal. US (28.2 L)
-
Cylinders: Twin
-
Engine Start: Ignition Key
-
Engine Oil Capacity: 2.0 qt. US (1.89 L)
-
Lubrication: Fully pressurized
-
Charging System: 15 amp regulated
-
Fuel Gauge: Electronic
-
Choke: Separate Choke
-
Air Filter: High Density
-
Oil Filter: Yes
-
Fuel Delivery: Carburetor
Drive System
-
Transmission: Parker HTG 16cc pump / 310cc wheel motor
-
Forward Speed: 14 mph / 22.5 km/h
-
Reverse Speed: 6 mph / 9.5 km/h
Cutting Deck
-
Deck Cutting Width: 0 in
-
Deck Material: fabricated 7ga. (.187”) steel shell
-
Deck Engagement (PTO): electronic fingertip engagement pto
-
Deck Construction: 7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge
-
Spindle Construction: " sealed cast aluminum housing (maintenance-free)
-
Blade(s): 3 high-lift Marbain® blades / 18,500 fpm (approx.)
-
Cutting Height Range: 1” to 5” in 1/4” increments
-
Anti-Scalping: 2 front deck gauge wheels
-
Deck Positions: Foot pedal with spring assist 16 Positions
Warranty
-
Warranty: 3 year / no hour limit commercial warranty and 5 year / 1,750 hour limited deck construction warranty
-
Deck Shell Warranty: 5 year / 1,750 hour limited deck construction warranty
-
Commercial Warranty: 3 year / no hour limit commercial warranty
Chassis
-
Frame: Fully welded, full-length 3/8 x 5" laser cut steel / integrated tie-down slots
-
Front Axle: 2" x 3" solid axle tube with ISO dampening suspension
-
ROPS: 2" x 2" spring-latch tool-less foldable 3 position
-
Bumper: 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
-
Yokes: 1/2" thick steel front yokes
Controls
-
Cruise Control: NA
-
Brakes: Hand-operated lever with integrated hydro pump release lever
-
Steering Control: High Performance Steering Wheel with electronic power steering & Foot-pedal Control
Comfort
-
Seat Type: Cushion with seat belt
-
Armrests: Padded arm rests
-
Seat Suspension: High-back Air-Ride suspension with EVC cushion, ISO mounted base (lateral suspension)
-
Seat Adjustment: Angle back adjust and lumbar support
Wheels
-
Rear Tires: 26"x12"-12"
-
Front Tires: 16"x6.5"-8"Kenda K505
-
Tire Tread: Turf Tread
Dimensions
-
Dimensions L/W/H: 88" L x 73" W x 48" H
-
Weight (approx.): 1580 lbs.
Additional Specifications
-
Hour Meter: Crew Boss
-
Discharge Chute: High-density, impact-resistant rubber
-
Cup Holder: Integrated into Side Pod
-
Model Number: 53TIHMUV050
Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
