Product Highlights
- 54-inch 10-gauge-steel fabricated deck with 7-gauge top and bottom reinforcements for added durability
- Commercial-grade electric-start 18.5 hp Kawasaki® engine (603cc)
- Hand-lever steering control with ball bearing linkage for smooth handling
Product Specifications
Engine
-
Engine Brand: Kawasaki®
-
Engine Model: FS Series
-
Engine Model Number: 600V
-
Engine Displacement: 603cc
-
Engine Output: 18.5HP
-
Fuel Tank Capacity: 5 gal. US (18.9 L)
-
Cylinders: Twin
-
Engine Start: Ignition Key
-
Engine Oil Capacity: 2.0 qt. US (1.89 L)
-
Lubrication: Fully pressurized
-
Charging System: 15 amp regulated
-
Fuel Gauge: No
-
Choke: Separate Choke
-
Air Filter: High Density
-
Oil Filter: Yes
-
Fuel Delivery: Carburetor
Drive System
-
Transmission: Hydro-Gear® ZT 2800 charged (commercial-grade)
-
Forward Speed: 7 mph / 11.3 km/h
-
Reverse Speed: 3 mph / 4.8 km/h
Cutting Deck
-
Deck Cutting Width: 54 in
-
Deck Material: Fabricated
-
Deck Construction: Fixed floating, fabricated 10ga. (.135”) steel shell
-
Spindle Construction: 5" sealed cast aluminum housing (maintenance-free)
-
Blade(s): 3 high-lift Marbain® blades / 18,500 fpm (approx.)
-
Cutting Height Range: 1.5" - 4.5"
-
Anti-Scalping: 2 front deck gauge wheels
-
Deck Positions: 4-pin manual with deck-mounted lift handles / 7 positions
Warranty
-
Warranty: 2 year / no-hour-limit commercial warranty
-
Commercial Warranty: 2 year / no-hour-limit commercial warranty
Chassis
-
Frame: Operator Tower with 7ga. Construction, 1.5 x 3" fully welded tube
-
Front Axle: Frame-mounted foot pedal front-end lift assist
Controls
-
Cruise Control: Single-lever cruise control (0-7 MPH)
-
Brakes: Hand-operated lever
-
Steering Control: Hand-lever steering control with ball bearing linkage for smooth feel
Wheels
-
Rear Tires: 18x8.5-8
-
Front Tires: 11x4-5 RF
-
Tire Tread: Turf Master
Dimensions
-
Dimensions L/W/H: 77" x 50"/61" x 46"
-
Weight (approx.): 665 lbs
Additional Specifications
-
Hour Meter: Basic Hour Meter (no tach)
-
Discharge Chute: High-density, impact-resistant rubber
-
Model Number: 55RI6HNV050
Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
